Ideapack Cobra Compact 320 Thermoformer
Thermoformer
3 Different Models
The Ideapack COBRA COMPACT 320 automatic thermoforming machine.
The COBRA COMPACT 320 allows high productivity rates, guarantees a reduction in material costs.
The COBRA COMPACT 320 is characterised by its reliability, ease of cleaning and maintenance, simple operating programs and simplicity in changing the format.
The COBRA COMPACT 320 improves the quality of the products through a rigorous control of the gases remaining in the tray, via a precision electronic sensor.
We can also offer
dispenser
automatic weigher
printer
photocell for the printed film
cooling unit
filter for dust or liquids
label maker
Machine dimensions 3500x1150x1700 mm
Loading area 600 mm (depends on the size of the mold)
Approximate weight 700 kg
Stainless steel structure AISI 304 (AISI 316 if required)
Check PLC
Power supply 400V (3ph+N+PE)
Power Min. 8 KW
Compressed air 6 bars
Indicative cycles/minute 10 sealing only; 8 empty only; 6 in a modified atmosphere
Vacuum pump 100 - 150 m3/h or higher on request
Max mold dimensions 290x300 mm
Max tray dimensions 1 cable: 290x300x100 mm
Max film width (top/bottom) 320/310 mm
Max film diameter (top/bottom) 300/300 mm
Electrical components Schneider Electric - Siemens
Pneumatic components AirTAC - SMC
Protection class IP 57
Usable film Flexible and Rigid
Ideapack COBRA 420 automatic thermoforming machine is consistent with a more sophisticated need in terms of speed in packaging.
The COBRA 420 allows high productivity rates, guarantees a reduction in material costs.
The COBRA 420 is characterised by its reliability, ease of cleaning and maintenance, simplified operating programs and simplicity in changing the format.
The COBRA 420 improves the quality of the products through a rigorous control of the gases remaining in the tray, via a precision electronic sensor.
Main accessories:
Dispenser
Automatic Weigher
printer
photocell for the printed film
shaped cut
cooling unit
filter for dust or liquids
label maker
conveyed discharges
jumbo roll
vibrating plane
Available in models:
Machine size 5500x1350x2000 mm
Loading area 1100 mm (depends on mold size)
Approximate weight 1000 kg
Stainless steel structure AISI 304 (AISI 316 if required)
Check PLC
Power supply 400V (3ph+N+PE)
Power Min. 12-15 KW
Compressed air 6 bars
Indicative cycles/minute 14 sealing only; 12 empty only; 10 in a modified atmosphere
Vacuum pump 150 - 300 m3/h or higher on request
Max mold dimensions 400x400 mm
Max tray dimensions 1 cable: 400x400x100 mm
Max film width (top/bottom) 430/420 mm
Max film diameter (top/bottom) 350/350 mm
Electrical components Schneider Electric - Siemens
Pneumatic components AirTAC - SMC
Degree of protection IP 57
Usable film Flexible or Rigid
Ideapack COBRA 660 automatic thermoforming machine satisfies the most demanding needs in terms of speed in packaging.
The COBRA 660 allows high productivity rates, guarantees a reduction in material costs.
The COBRA 660 is characterised by its reliability, ease of cleaning and maintenance, simplified operating programs and simplicity in changing the format.
Ideapack COBRA 660 improves the quality of the products through a rigorous control of the gases remaining in the tray, via a precision electronic sensor, and thanks to its compliance with the European Union Regulation 1935/20047EC, which defines the requirements of the materials intended to enter in contact with food.
Main accessories:
dispenser
automatic weigher
printer
photocell for the printed film
shaped cut
cooling unit
filter for dust or liquids
double reel holder with expansion shafts
rapid pneumatic mold change
label maker
conveyed discharges
jumbo roll
vibrating plane
Machine dimensions From 10000x1500x2000 mm
Loading area Tailored
Approximate weight From 1000 kg
Stainless steel structure AISI 304 (AISI 316 if required)
Check PLC
Power supply 400V (3ph+N+PE)
Power Min. 12 KW
Compressed air 6 bars
Max cycles/minute 18 sealing only; 16 empty only; 14 in a modified atmosphere
Vacuum pump 300 m3/h or higher on request
Max mold dimensions Tailored
Max tray dimensions Tailored
Max film width (top/bottom) 660 mm
Max film diameter (top/bottom) 400/400 mm (jumbo roll available)
Electrical components Schneider Electric - Siemens
Pneumatic components AirTAC -SMC
Degree of protection IP 57
Film used Flexible and Rigid
